Rigid constructs with few components and minimal steps

The XtraFix External Fixation System allows surgeons to build rigid constructs for long bone and pelvic fractures with few components and steps.


  • Tibia, Hip & Femur

Product Type

  • External Fixation

System Features



Streamlined Workflow

  • All pins and instruments are color coded to simplify steps for the surgical team. Each pin, whether it is a 5mm/6mm diameter shank (XtraFix Large 11mm System) or a 4mm diameter shank (XtraFix Small 6mm System), is also sized to reduce overall clamp inventory.

Variable Options for Best Fit

  • Components are available in a wide selection of pin and bar diameters and lengths. Transitioning from XtraFix Large 11mm to Small 6mm components on the same frame is facilitated by XtraFix Large 11mm Pin-to-Bar Clamps.


  • Efficiency Multi-Pin Clamps have 2-Bar and 1-Bar jaw attachments built-in to the clamp with the goal of reducing the number of components required to construct a frame. Quick- connect ends are designed into pins and drills to save time during implantation.
  • All clamps have a SnapLoc latch that actively prevents bars and pins from popping out. Clamps also feature one-nut tightening designed to save time intra-operatively.


XtraFix External Fixation Video

XtraFix Instruments

Tailored resources for your patients.

Find videos, articles, and interactive content to guide your patients throughout their surgical journey on ReadyPatient.com, our dedicated patient recovery site.
